One-off pieces, detailed like production work.
Drawings for individual furniture pieces — joint sizes, grain direction and finishing schedules all on the sheet, so a one-off can be built twice if it ever needs to be.
SOLIDWORKSSWOODKEYSHOTAUTOCADPOLYBOARD
++
FIG.94 — WALNUT SIDEBOARD · REV.1
CLICK TO EXPLODE / ASSEMBLE
WALNUT SIDEBOARDREV.1FIG.94SOLID WALNUT · OAK VENEERSCALE 1:10SHT 1/7
SVC.03.D — FURNITURE INDEX, SEVEN LINES
Joints, grain and finish,
all on the sheet
TRADITIONAL JOINERY DRAWN TO MODERN TOLERANCES — RENDERED BEFORE IT IS CUT
.01Piece Drawings & Full-Size DetailsPlans, elevations and full-size joint details for tables, seating, casegoods and one-off commissions.
.02Traditional Joint DetailingMortise and tenon, dovetail, domino and loose-tongue joints drawn with sizes, shoulder positions and glue-up sequence.
.03Timber & Veneer SpecificationSolid oak and walnut sections, veneer leaves and substrate build-ups specified with grain direction marked on every component.
.04Curved & Laminated ComponentsBent laminations, formers and vacuum-press build-ups detailed with lay-up counts and spring-back allowances.
.05Hardware, Fittings & MechanismsConcealed fittings, soft-close mechanisms and Hafele connectors scheduled and positioned on the component drawing.
.06Photoreal Renders for ApprovalKeyShot visuals in the specified timber and finish, produced from the model the workshop will build from.
.07Cut Lists, Machining & Finishing SchedulesRough and finished sizes, machining order and the finishing spec — from sanding grit to the final lacquer or oil coat.
PROCESS — FOUR CHECKPOINTS
How a one-off gets drawn
STEP.01
Design intent
Sketches, references and dimensional constraints reviewed with the maker before any geometry is committed.
STEP.02
Fixed quote
A written quote inside 24 hours, covering drawings, renders and one full round of revisions.
STEP.03
Model & render
The piece is modelled and rendered for approval — proportion and finish agreed before joint detailing begins.
STEP.04
Bench pack
Piece drawings, joint details, cut lists and finishing schedules issued as one independently checked set.
SECTORS —FURNITURE MAKERSRESIDENTIALHOSPITALITYARCHITECTURAL JOINERYINTERIOR DESIGNERSGALLERIES & EXHIBITIONYACHT & MARINE
Pieces we've drawn
ALL WORK →DROP RENDER — FIG.94
WALNUT SIDEBOARDFIG.94
DROP RENDER — FIG.95
BOARDROOM TABLEFIG.95
DROP RENDER — FIG.96
CURVED STAIR BALUSTRADEFIG.96
DROP RENDER — FIG.97
LAMINATED LOUNGE CHAIRFIG.97
DROP RENDER — FIG.98
OAK DINING BENCHFIG.98
DROP RENDER — FIG.99
VENEERED DRINKS CABINETFIG.99
OUR CLIENTS — ON THE RECORD
Signed off, worldwide
REG.014 — SIGN-OFF
“Very well thought out and articulate communication. Clear milestones, deadlines and fast work. No shortcuts. The best part — always solving problems with great original ideas.”
COURTNEY HENRYCUSTOMER IN U.S.A
ORIGINUSASERVICEBESPOKE FURNITURESTATUSAPPROVED ✓
SHT 1 / 3
RFI LOG — MOST FREQUENT QUESTIONS
Before you ask
Yes — a sketch, a dimension or two and a reference photo is enough to start. The first output is a model and a render for you to react to.
Have a piece in mind?
Send the sketch.
